Sugatsune Heavy Duty Concealed Cabinet Door Hinge - Inset Mounting Plate Unsprung - Black Nickel
Sugatsune Heavy Duty Concealed Cabinet Door Hinge - Inset Unsprung - Black Nickel is designed to deliver durable and precise... More info
| Product name | Variant code | Data sheet | Price | Quantity | ||
|---|---|---|---|---|---|---|
| Sugatsune Heavy Duty Concealed Cabinet Door Hinge - Inset Unsprung - Black Nickel | In Stock | ACH09505B | Download | £17.30 ex VAT |
|
|
| Sugatsune Heavy Duty Concealed Cabinet Door Hinge - Inset Mounting Plate Unsprung - Black Nickel | In Stock | ACH09505B.MP | Download | £24.24 ex VAT |
|
Compare Sugatsune Heavy Duty Concealed Cabinet Door Hinge - Inset Mounting Plate Unsprung - Black Nickel
Sugatsune Heavy Duty Concealed Cabinet Door Hinge - Inset Unsprung - Black Nickel is designed to deliver durable and precise hinge performance in inset cabinet applications where controlled, non self-closing operation is required. Manufactured by Sugatsune, a globally recognised specialist in precision architectural and furniture hardware, this hinge combines robust construction with a contemporary finish, making it suitable for both functional and design-led cabinetry.
Designed specifically for inset cabinet doors, the hinge allows the door to sit flush within the cabinet frame, supporting clean architectural lines and accurate reveals. The concealed hinge design ensures all mechanical components remain hidden when the door is closed, contributing to a refined and professional cabinet appearance.
The unsprung mechanism allows the door to move freely without automatic self-closing action, making it suitable for installations where doors are required to remain in position or where external soft-close systems are specified. This provides flexibility across a range of cabinet designs and functional requirements.
Finished in a Black Nickel coating, the hinge offers a modern aesthetic suited to contemporary cabinetry and coordinated dark hardware schemes. Its heavy-duty construction supports reliable operation for larger or heavier doors, while three-dimensional adjustment enables precise vertical, lateral and depth positioning to achieve accurate alignment and consistent door gaps.
Product Features
- Heavy duty concealed cabinet hinge
- Inset door configuration for flush cabinet alignment
- Unsprung mechanism for free door movement
- Concealed hinge design for clean cabinet aesthetics
- Black Nickel finish for contemporary interiors
- Three-dimensional adjustment for precise positioning
Product Benefits
- Allows controlled or free-position door operation
- Supports clean inset cabinet design and flush alignment
- Enhances cabinet appearance with concealed hardware
- Provides stable and durable hinge performance
- Enables accurate alignment and consistent reveals
- Suitable for residential and commercial cabinetry
Technical Characteristics
- Concealed hinge construction
- Designed for inset cabinet door applications
- Unsprung (non self-closing) hinge operation
- Black Nickel surface finish
- Three-way adjustment: vertical, lateral and depth
- Compatible with concealed hinge mounting systems
Applications
This hinge is intended for inset cabinet door installations across kitchens, wardrobes, office furniture and commercial joinery where non self-closing operation is required. It is particularly suitable for applications using external damping systems or where doors must remain in position. The concealed design ensures a clean and flush cabinet finish, while the Black Nickel finish makes it ideal for contemporary interiors and coordinated dark hardware schemes.
| Sugatsune Heavy Duty Concealed Cabinet Door Hinge - Inset Unsprung - Black Nickel | Sugatsune Heavy Duty Concealed Cabinet Door Hinge - Inset Mounting Plate Unsprung - Black Nickel | |
|---|---|---|
| Finish | Black Nickel | Black Nickel |
| Opening angle (°) | 93 | 93 |
| Application | Inset | Inset |
| Closing Mechanism | Unsprung | Unsprung |
| Max Door Thickness (mm) | 30 | 30 |
| Max Door Weight (kg) - 2 Hinges | 25 | 25 |
| Max Door Weight (kg) - 3 Hinges | 40 | 40 |
| Hinge Type | Heavy Duty | Heavy Duty |
