Sugatsune 3-Way Adjustable Concealed Hinge - Min 19mm Door Thickness
Sugatsune 3-Way Adjustable Concealed Hinge - Min 19mm Door Thickness is designed to provide precise door alignment and concealed installation... More info
| Product name | Variant code | Data sheet | Price | Quantity | ||
|---|---|---|---|---|---|---|
| Sugatsune 3-Way Adjustable Concealed Hinge - Min 19mm Door Thickness - Black | In Stock | HA3D-19BK | Download | £27.14 ex VAT |
|
|
| Sugatsune 3-Way Adjustable Concealed Hinge - Min 19mm Door Thickness - Silver | In Stock | HA3D-19SI | Download | £25.50 ex VAT |
|
|
| Sugatsune 3-Way Adjustable Concealed Hinge - Min 19mm Door Thickness - Satin Nickel | In Stock | HA3D-19SN | Download | £27.05 ex VAT |
|
Compare Sugatsune 3-Way Adjustable Concealed Hinge - Min 19mm Door Thickness
Sugatsune 3-Way Adjustable Concealed Hinge - Min 19mm Door Thickness is designed to provide precise door alignment and concealed installation for cabinetry requiring a clean, uninterrupted finish. Engineered by Sugatsune, a specialist in high-quality architectural hardware, this hinge delivers three-way adjustment capability, allowing accurate positioning during installation and fine-tuning over time.
Designed for doors with a minimum thickness of 19mm, the hinge is suitable for applications where structural strength and stability are required. Its concealed design ensures the hinge remains hidden when the door is closed, supporting a minimalist and modern aesthetic. The hinge enables vertical, lateral and depth adjustment, allowing installers to achieve consistent reveals and smooth door operation across multiple units.
Available in multiple finishes including Black, Satin Nickel and Silver, the hinge can be specified to suit a wide range of cabinetry styles and hardware schemes. Manufactured from durable materials, it is built to withstand repeated use while maintaining alignment and performance.
Product Features
- Three-way adjustment (vertical, lateral and depth)
- Designed for minimum 19mm door thickness
- Concealed hinge design for clean aesthetics
- Provides precise door alignment capability
- Available in Black, Satin Nickel and Silver finishes
- Durable construction for long-term performance
Product Benefits
- Enables accurate and consistent door positioning
- Supports clean, minimalist cabinetry designs
- Reduces installation time through adjustability
- Maintains alignment during long-term use
- Allows finish coordination with surrounding hardware
- Suitable for residential and commercial interiors
Technical Characteristics
- Designed for concealed installation within cabinet doors
- Requires door thickness of minimum 19mm
- Adjustable in three directions for precise fitting
- Suitable for integration into cabinet carcass and door systems
- Supports consistent gap and reveal alignment
- Engineered for durability and repeated use
Applications
This hinge is suitable for kitchen cabinetry, wardrobes, furniture doors and architectural joinery where concealed hardware and precise alignment are required. It is particularly effective in applications demanding a clean exterior appearance, such as modern fitted furniture, display units and high-end cabinetry, where both aesthetic consistency and reliable performance are essential.
| Sugatsune 3-Way Adjustable Concealed Hinge - Min 19mm Door Thickness - Black | Sugatsune 3-Way Adjustable Concealed Hinge - Min 19mm Door Thickness - Silver | Sugatsune 3-Way Adjustable Concealed Hinge - Min 19mm Door Thickness - Satin Nickel | |
|---|---|---|---|
| Colour | Black | Silver | Satin Nickel |
| Opening angle (°) | 180 | 180 | - |
| Weight (kg) | 95 | 95 | - |
| Max Door Thickness (mm) | 19 | - | - |
| Max Door Width (mm) | 600 | 600 | - |
| Door Height (mm) | Max 1200 | Max 1200 | - |
| Max Door Weight (kg) - 2 Hinges | 9 | 9 | - |
| Max Door Weight (kg) - 3 Hinges | 12 | 12 | - |
| Max Glass Thickness (mm) | - | 19 | - |
